Side or Rear Discharge, Front or Rear 3PT Mounting Right Hyd Offsetable Deck, Hyd Side Trim Positioning Manual or Hyd Side Trim Head Spring Swingback Sensitivity Setting Left Side Trim Head for Hwy DOT Mowing Available Widest w/Single Side Trimming Head
(6’ to 11’ Widths, 30-100HP)
Efficiently Precise Single Pass Results Commercial Quality Rotary Mowers with All the Best Features, Superior Cuts and Safest Operations
Generous Overlap Between Main Deck & Side Trimmer Blades Ensures Single Pass Perfection Multiple ‘On-The-Fly’ Hydraulic Operator Adjustments for Single Pass Precision Fully Shrouded Deck & Side Trim Head for Crop Protection & Operator Safety Low Profile Deck & Side Trim Head for Fence Row Aisles & Sides of Structures Excellent Fit, Finish & Performance with Safety & Efficiency! EQUIPMENT THAT WORKS FOR YOU!
Double Sided Blades & Reversible Hitch for Rear or Front 3Pt Mounting.
EMG Models Offer Widest Working Widths w/Single Side Trim Head.
Right Offsetable Center Deck:
Shown in above video at 0:45 thru 0:50.
Also Depicts 2-Hydraulic Functions: 1 For Side Trim Head, 1 For Deck Offset.
Large 31” Diameter Side Trim Head for Maximum ‘Wrap Around’ Cutting Effect.
Manual or Hydraulic Spring Tensioning for Side Trim Head Swingback Sensitivity Adjustment.
Hydraulic Side Trim Head Adjustment (CW & CCW):
Shown in above video at 0:45 thru 0:47.
Side Trim Head can be Mechanically Locked in Retracted Position for Transport.
Discharge Location Selectable: Side to Crop Base, or Rear to Aisleway.
Weight Balanced Side Trim Head for Synchronized Positioning with Main Deck.
Steel Front Gage Wheels & Rear Roller for Cutting Height Adjustment.
Cat 1 & 2 Suitable.
540RPM PTO Shaft.
Expect Excellent Fit, Finish & Performance with All Ilmer Products Current Hitch Version is Reversible for Front & Rear Mounting Adjustable Depth Positioning of Deck Accommodates Various Pull Arm Lengths
Sensitive Swing Back for Gentle Crop Protection Ground Speed & Sensitivity Settings Work Together for the Best Results!
EMG 345/72 Shown at work with Optional Trip Wire
EMG Series (w/Single Side Trim Head) Offers the Widest Working Widths for the Widest Aisleways! Up to an 11’-2” Wide Cut with the Model 345/72
Front or Rear Mountable EMG Series For Improved Visibility Hitches Are now Reversible, not Double as Shown in Above Photo.
Left Side Mounted Side Trimmer Head (Head in retracted position) Accommodates Driving with Direction of Traffic During Freeway, Guard Rail, Highway, Interstate & Roadside Maintenance Mowing!
EMG SERIES AISLEWAY & SIDE TRIMMING MOWERS SPECIFICATIONS
MODEL
215/48
225/58
235/72
245/48
255/58
265/72
275/48
285/58
295/72
315/48
330/58
345/72
Tractor HP
30 - 120
35 - 120
40 - 120
45 - 120
50 - 120
Working Width
Deck
71"
71"
71"
81"
81"
81"
95"
95"
95"
110"
110"
110"
S.T. Head Dia.
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
Total Working Width w/S.T. Head Extended
85" (215)
89" (225)
93" (235)
97" (245)
101" (255)
105" (265)
109" (275)
112" (285)
116" (295)
124" (315)
130" (330)
136" (345)
Blade Overlap of Deck & S.T. Head
5"
5"
6"
3"
3"
4"
5"
6"
3"
5"
3"
2"
(Right) Offset
30"
31"
32"
Overall Width*
73"
85"
97"
113"
Overall Depth*
63"
67"
71"
65"
69"
73"
67"
71"
75"
73"
77"
81"
Hitch
CAT 1 & 2
Front or Rear
Qty Blades/Spindles
3-Deck & 1 Side Trim Head
Weight
1,179lb's
1,191lb's
1,202lb's
1,246lb's
1,257lb's
1,268lb's
1,356lb's
1,367lb's
1,378lb's
1,665lb's
1,676lb's
1,687lb's
Legend: * = with S.T.H. Locked Back In Transport Position S.T.H. = Side Trim Head
Weights are Less Pallets, Crates & PTO Shaft.
EMG SERIES AISLEWAY & SIDE TRIMMING MOWERS SPECIFICATIONS
MODEL
215/48
225/58
235/72
245/48
255/58
265/72
275/48
285/58
295/72
315/48
330/58
345/72
Tractor HP
30 - 120
35 - 120
40 - 120
45 - 120
50 - 120
Working Width
Deck
71"
71"
71"
81"
81"
81"
95"
95"
95"
110"
110"
110"
S.T. Head Dia.
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
19" (48)
23" (58)
28" (72)
Total Working Width w/S.T. Head Extended
85" (215)
89" (225)
93" (235)
97" (245)
101" (255)
105" (265)
109" (275)
112" (285)
116" (295)
124" (315)
130" (330)
136" (345)
Blade Overlap of Deck & S.T. Head
5"
5"
6"
3"
3"
4"
5"
6"
3"
5"
3"
2"
(Right) Offset
30"
31"
32"
Overall Width*
73"
85"
97"
113"
Overall Depth*
63"
67"
71"
65"
69"
73"
67"
71"
75"
73"
77"
81"
Hitch
CAT 1 & 2
Front or Rear
Qty Blades/Spindles
3-Deck & 1 Side Trim Head
Weight
1,179lb's
1,191lb's
1,202lb's
1,246lb's
1,257lb's
1,268lb's
1,356lb's
1,367lb's
1,378lb's
1,665lb's
1,676lb's
1,687lb's
Legend: * = with S.T.H. Locked Back In Transport Position S.T.H. = Side Trim Head
Weights are Less Pallets, Crates & PTO Shaft.
Specifications & Designs Are Subject to Change Without Notice
