Municipal, Commercial & Private Green Spaces, Lawns & Turf!
The ‘500 & 600G’ Series ‘Grooming TriDeck’ is available with Large Forged & Hardened Hammer Blades, or with ‘Y’ Blades!
Use the ‘Y’ Blades for least demand transfer to your Tractor, allowing smaller/lower hp Tractors to be used on turf.
Also use the '500 & 600G' Series with the ‘Y’ Blades if Rough Cutting with lower hp tractors!
Use the Hammer Blades for a Flat & Carpet like Finish Cut, and a bit longer blade life,
or if Rough Cutting in areas free of debris!
Use The ‘R’ Series Rough Cut Mower For:
Excellent Rough Cutting, Land Clearing & Maintenance Results In The Efficiency of a Single Pass On:
The Tallest, Thickest, Most Demanding Stands of Vegetation in Fields, On Highway & Roadside Shoulders, Medians & Ditches,
In Right of Way Mowing & Clearing, For Cover Crop, or Unharvested Produce Mulching, and Much, Much More!
The '500 & 600R' Series ‘Rough Cut TriDeck’ is available with Large Forged & Hardened Hammer Blades, or with 'L' Blades!
Use the Larger Hammer Blades for Rigorous Rough Cutting on Tractors with Sufficient hp,
and also in areas Where Debris, and other Trash may be present! These Larger Blades perform well
in Finish Cutting applications too, but for the best finish cut, the Blades must be as sharp as possible!
Updated Videos Coming Soon!
Updated Videos Coming Soon!
OMARV ‘G’ & ‘R’ Series Large Area, TriDeck Flail Mowers Are Equipped With 19” Dia (Blade Tip to Blade Tip) Severe Duty Rotors That Are Very Highly Populated With Blades to Provide The Best Possible Cut & Reduce The Burden on Your Tractor!
OMARV Mower Gear Boxes Include an Over-Running Clutch, Which Provides Two Advantages:
First, Easy Alignment & Attachment of the Mowers PTO Shaft to the Tractors PTO Shaft:
The O.R. Clutch Enables you to Freely Spin the PTO Shaft & Gearbox for Alignment!
Second, Smooth Shut Down:
The O.R. Clutch Allows the Mower Gearbox to Free Wheel to a Stop, Eliminating Abrupt Shutdowns & Wear of the PTO Brake!
A Large, Deep Deck Enclosure Accommodates Higher Volumes of Material for Superior Finish Results, Superior Mulching Results, Less Burden Transferred to the Tractor & Better Ground Speeds. It's Also Large Enough for the Rear Roller to be Within the Footprint of the Deck (instead of protruding out beyond the back).
The Large Deck Enclosure is Also Large Enough to Have an Adjustable Mulching Door (placed above the roller & behind the rear deflector)!
Under Deck Mulching Counter Blade Ensures Reduction of Larger Clippings & Further Reduces Smaller Ones.
Requires One Set of Hydraulic Outlets With Float Positioning. Float Positioning Allows Contour Following of The Decks, Prevents Scalping & Prevents Raising the Outer Decks While the PTO is Engaged (which would damage the PTO U-Joints).
All 3 Hydraulic Cylinders Are Double Acting, Which Allows Superior Control (over single acting cyl's) & Also Allows For Down Pressure on the Decks.
Terrain Scalping is Avoided with the Rear Rollers, Gage Wheels, Float Capability & Adjustable Rear Transport Axle.
Gage Wheels Provide Deck Suspension & Cutting Height Adjustment (1-1/2"-6").
Rear Roller (on each deck) Provides Mower Deck Suspension & Cutting Height Adjustment.
Plus, the Transport Axle & Tires Provide Deck Suspension, Cutting Height Adjustment & Overall Vertical Positioning for the Mower.
One Of The Many Multi-Purpose Characteristics of OMARV Flail Mowers Is That They Provide A Superior Rough Cut (compared to any 'rotary rough cut mower') & A Superior Finish Cut (compared to any 'rotary finish cut mower')! Plus With the 'Forged & Hardened' Hammer Blades on This Flail Mower, You Can Cut 4" Diameter Material & Still Get A Superior Finish Cut Too!
Single Location, Manifolded Grease Zerk’s Provide Access Convenience & Prevent Missing Some Lubrication Points!
Powder Coated Paint.
Mowers Ship Assembled & Ready To Use:
This Means No Assembly Headaches from Poor Instructions, No Missing Parts & Associated Delays, No Special Tools, No Knuckle Busters & No Waiting Until It's Assembled Before First Use!
All of These Excellent Features Work Together to Outperform Your Expectations in Rough Cutting, Mulching & Finish Cutting Applications, With Beautiful, Single Pass Results, With Efficient Ground Speeds & With Ease of Demand on Your Costly Tractor & it's Fuel Tank! Most of All, it Makes Mowing Fun Again!
OMARV 680G In Transport Position
OMARV 680G Finish Mowing In Public Green Space
OMARV Flail Mowers Are The Safest & Most Efficient Mowers Available:
With OMARV Flail Mowers, The Possibility of Discharging Dangerous Projectiles is Dramatically Reduced Compared to Conventional Rotary Mowers, and With The Reduced Machine Depth & Weight, They're The Easiest For Your Tractor to Handle! As Mentioned Previously, Rear Visibility is Another Indispensable Safety Feature. Plus, the Superior ‘Single-Pass’ Cut of Peruzzo Flail Mowers Provides New Efficiencies By Eliminating Multiple Passes For Excellent Results!
OMARV 'TRIPLEX' SERIES SPECIFICATIONS
MODEL
520-G
520-R
560-G
560-R
600-G
600-R
Horsepower
100 - 135HP
130 - 180HP
Working Width
17'-1"
18'-4"
19'-8"
Overall Width
18'-4"
19'-8"
21'-0"
Folded Width
8'-2"
Number of Hammer Blades
124
136
144
Number of Knife Blades
248
272
288
CUTTING HEIGHT
'Y' Blades
1.25" - 4.5"
N/A
1.25" - 4.5"
N/A
1.25" - 4.5"
N/A
'L' Blades
0.75" - 6"
Hammer Blades
0.75" - 6"
Weight
3,373 lb's
3,946 lb's
4,189 lb's
Weights are Less Pallets, Crates & PTO Shaft.
OMARV 'TRIPLEX' SERIES SPECIFICATIONS
MODEL
520-G
520-R
560-G
560-R
600-G
600-R
Horsepower
100 - 135HP
130 - 180HP
Working Width
17'-1"
18'-4"
19'-8"
Overall Width
18'-4"
19'-8"
21'-0"
Folded Width
8'-2"
Number of Hammer Blades
124
136
144
Number of Knife Blades
248
272
288
CUTTING HEIGHT
'Y' Blades
1.25" - 4.5"
N/A
1.25" - 4.5"
N/A
1.25" - 4.5"
N/A
'L' Blades
0.75" - 6"
Hammer Blades
0.75" - 6"
Weight
3,373 lb's
3,946 lb's
4,189 lb's
Weights are Less Pallets, Crates & PTO Shaft.
Specifications & Designs Are Subject to Change Without Notice
