Selvatici Series B180.250S 3-Point Spading Machines -- Iowa Farm Equipment

Selvatici Series B180.250S 'Bivanga' Double Blade & Depth
Tractor 3-Point Spaders, Spading Machines

Bullet Proof, Durable, Low Demand Machines Producing Unparalleled Results!

Video of Selvatici Series 150.150, Model B2208P At Work In Greenhouse Building, Operating At Low Gear Box Speed!

The B180.250S Series Spaders Are Suitable For Utility & Higher HP Tractors, With Working Widths Up To 14’. They Provide Highly Concentrated Soil Penetrations From 6" to 30" Deep, Efficiently, in a Single Pass.

STANDARD FEATURES:

Heavy Duty, 540 or 1000RPM, Large Sump 3-Speed Gearbox.
Slip Clutch Protected PTO Shaft.
Category 2, 3-Point Hitch with Clevis Style Hitch Pin Frames.
Multi-Speed Gearbox, with Easy Shift External Lever For Accommodating a Broad Range of Soil Types & Activities!
Selvatici's Wear-Resistant Spader Blades Use 'Ultra-High Strength Steel, Alloyed With 30MnB5 Boron' To Endure Tough Ground & Rocks!
Multiple Holding Positions of Rear Gate, From Open to Closed:
- Works in Conjunction with Multi-Speed Gearbox, For Varied Soil Results, and Varied Soil Moisture.
Multi-Positioned, Anti-Clogging Frame Also Accommodates Varied Soil Moisture Conditions.
Greaseable Bearings with Metal Seals For Extended (50hour) Intervals.
Skid Shoes For Easy, Tool Free Working Depth Control.

B180.250S SERIES SPECIFICATIONS
MODEL	B2008S	B2208S	B2510S	B3012S	B3514S	B4016S	B4516S
Working Width	79"	87"	96"	10'	11'-6"	13'-1"	14'-9"
Overall Width	81"	89"	98"	10'-2"	11'-8"	13'-3"	14'-11"
Minimum HP	80HP	80HP	90HP	110HP	120HP	140HP	150HP
Maximum HP	250HP
Min/Max Working Depth	6"/30"
Number of Spades	16	16	20	24	28	32	32
Gearbox Speeds @540RPM	109, 120, 133, 147, 163, 180, 199, 221 & 245RPM’s
Gearbox Speeds @1000RPM	117, 131, 147, 164, 182, 202, 223 & 247RPM’s
Weight	4,202lbs.	4,334lbs.	4,972lbs.	5,742lbs.	6,930lbs.	7,766lbs.	8,206lbs.

B180.250S SERIES SPECIFICATIONS
MODEL	B2008S	B2208S	B2510S	B3012S	B3514S	B4016S	B4516S
Working Width	79"	87"	96"	10'	11'-6"	13'-1"	14'-9"
Overall Width	81"	89"	98"	10'-2"	11'-8"	13'-3"	14'-11"
Minimum HP	80HP	80HP	90HP	110HP	120HP	140HP	150HP
Maximum HP	250HP
Min/Max Working Depth	6"/30"
Number of Spades	16	16	20	24	28	32	32
Gearbox Speeds @540RPM	109, 120, 133, 147, 163, 180, 199, 221 & 245RPM’s
Gearbox Speeds @1000RPM	117, 131, 147, 164, 182, 202, 223 & 247RPM’s
Weight	4,202lbs.	4,334lbs.	4,972lbs.	5,742lbs.	6,930lbs.	7,766lbs.	8,206lbs.

Specifications & Designs Are Subject to Change Without Notice
